Pump head flow range 0.3~6000 ml/min
It is suitable for 15 #, 24 #, 35 # and 36 # hoses and can realize the use of multiple pump heads in series
The roller assembly is made of stainless steel 304 material with excellent mechanical properties and can work continuously for a long time at high speed
The shell is made of PPS, acid hydrolysis resistant and organic solvent resistant.
It is suitable for 15 #, 24 #, 35 # and 36 # hoses and can realize the use of multiple pump heads in series
The roller assembly is made of stainless steel 304 material with excellent mechanical properties and can work continuously for a long time at high speed
The shell is made of PPS, acid hydrolysis resistant and organic solvent resistant.
|
Number of channels |
1 |
| Number of rollers | 3 |
| Pressure pipe structure | Elastic adaptation |
| Speed range | 0.1-600rpm |
| Flow range | 0.3-6000ml/min |
| Transmission pressure | ≤0.2MPa |
| net weight | 2.02kg |
| Overall dimension | 128*66.6*112.5mm |
|
flexible pipe |
Maximum flowmL/min(600rpm) |
Ml/rev |
|
15# |
1800 |
3 |
|
24# |
3000 |
5 |
|
35# |
4500 |
7.5 |
|
36# |
6000 |
10 |
Flow parameter table
Dimensional drawing of long shaft pump head
Dimension drawing of short shaft pump head
